HSI Articulating Floor Mounted Jib Crane, 1 Ton

$25,924.61

Reviews (0)

SKU:: HANL-350AJ-4

Estimated Lead Time: 2-3 weeks

Description
Reviews
Additional Info

The Handling Systems International Freestanding Articulating Jib Crane is designed to position loads in hard to reach areas. The articulating boom makes it easy to maneuver around columns, corners, and through narrow passageways.

With true 360° articulation, the crane provides a large coverage area from the mast out to the tip of the outer arm. Compatible with hoists, manipulators, balancers, and vacuum lifters.

This self-supporting jib crane delivers a full 360° of rotation and mounts directly to the floor using HSI anchor bolts with either a recommended foundation or existing concrete, depending on crane specifications.

HSI Model 350AJ Freestanding Articulating Jib Crane, 1 Ton - 8' Span

NOTE: Price listed is for smallest size model #350FAJ-2000-8-8 (RFQ for pricing on others).

Model Number	CAPACITY LBS.	OVERALL SPAN	INNER ARM LENGTH	OUTER ARM LENGTH	HEIGHT UNDER BEAM	OUTER ARM HEIGHT	OVERALL HEIGHT	Approx. Weight
350FAJ-2000-8-8	2000	8	4’ 6”	3’ 6”	8’ 3”	8’ 10”	9’ 11-11/16”	1,267 lbs.
350FAJ-2000-8-10	2000	8	4’ 6”	3’ 6”	10’ 3”	10' 10"	11’ 11-11/16”	1392
350FAJ-2000-8-12	2000	8	4’ 6”	3’ 6”	12'-3"	12' 10"	13’ 11-11/16”	1760
350FAJ-2000-8-14	2000	8	4’ 6”	3’ 6”	14'-3"	14' 10"	15’ 11 -1/16”	1925
