All Lift Wall-Mounted Jib Crane, 1/2 Ton

All Lift Wall-Mounted Jib Crane, 1/2 Ton

$1,732.00

Reviews (0)

SKU:: ALLC-CW-Series-2

Estimated Lead Time: 2-3 weeks

Description
Reviews
Additional Info

Description

The All Lift Cantilevered Wall Mounted Jib Crane provides hoist coverage with up to 200° of rotation. Because it mounts directly to a wall or vertical building column, it can be installed very close to the underside of the lowest ceiling obstruction, maximizing available lift height for the hoist. The design consists of a vertical mast secured to two brackets on a wall or structural beam, with a boom that extends outward perpendicular from the mounting surface.

Well suited for individual use in bays, along walls, or between building columns. Also works as a supplement to an existing overhead crane or monorail system where additional point-of-use lifting is needed.

All Lift CW-Series Cantilevered Wall Mounted Jib Crane, 1/2 Ton - 8' to 20' Span

NOTE: Price listed is for smallest size model #CW108 (RFQ for pricing on others).

Capacity (Pounds)	Model	Span	Bracket Centers	Beam Height	Flange Width	Thrust & Pull	Weight lbs.
1000	CW108	8’	3’ – 0”	8”	5-1/4”	3,785#	365
1000	CW110	10’	3’ – 0”	8”	5-1/4”	4,750#	407
1000	CW112	12’	3’ – 0”	8”	5-1/4”	5,768#	449
1000	CW114	14’	4’ – 0”	8”	5-1/4”	5,145#	595
1000	CW116	16’	4’ – 0”	12”	6 ½”	6,125#	772
1000	CW118	18’	4’ – 0”	12”	6 ½”	6,950#	832
1000	CW120*	20’	6’ – 0”	12”	6 ½”	5,450#	988

*Bolt together design - All other models are WELDED.

Available Options (RFQ):

Tagline Festooning
Hoists & Trolleys
Rotation Stops

Installation Requirements:

Mounting bolts not included – use grade 5 or be er provided by the installer.
Allow for 3” clearance above and along entire length of boom.
Must have a structurally sound wall, column, or base for supporting the Jib Crane.
