Jet JDP-20EVS-110, 20" EVS Drill Press, 1-1/2" Drilling Capacity, 2HP, 115V/1PH, JT9-354220

$6,929.00

Reviews (0)

SKU:: JETJT9-354220

Description
Reviews
Additional Info

JET Electronic Variable Speed Drill Presses offer spindle speed rates between 65 and 2000 RPM for a wide variety of applications.

Designed to permit continuous speed adjustment - even during operation. Emergency stop and a heavy-duty casted head are but a few of the features JET includes to enhance overall use and accuracy.

Coolant system is optional #5512104
CSA/CUS Certified
Front Mounted LED Spindle RPM Readout
Front mounted positive control depth stop
Heavy-duty steel column for increased precision and rigidity
High torque at all speeds both forward and reverse
Large Hand Grips designed with the users comfort in mind
Large precision ground T-Slot production table for easy set ups
Latest AC Inverter Variable Speed Technology
Spindle is supported by high quality ball bearings

Stock Number	JT9-354220
Base Dimensions (In.)	27 x 19
Column Diameter (In.)	4-1/2
Distance Column to Spindle (In.)	10-7/16
Drilling Capacity Cast Iron (In.)	1-1/2
Drilling Capacity Mild Steel (In.)	1-3/8
Drills to Center of Circle (In.)	20
Inverter Type	115V, Single Phase
Model Number	JDP-20EVS-110
Motor (HP)	2 HP, 115V 1ph
Overall Dimensions (L x W x H) (In.)	38.18 x 27.16 x 79.52
Prop 65	Cancer and Reproductive Harm
Range of Spindle Speeds (RPM)	65-540 /245- 2,000
Spindle Distance to Base (In.)	44-1/2
Spindle Distance to Table (Max.) (In.)	30-1/4
Spindle Taper (In. x TPI)	MT-3
Spindle Travel (In.)	6
Style (Type)	Variable Speed
T-Slot Centers (In.)	7-7/16
Table Size (L x W) (In.)	22x18-3/4
Table Travel (In.)	20
Warranty	2 Year
Work Table Weight Capacity (Lbs.)	154
Gross Weight	792.0
Net weight	792.0
