Overhead Load Lifters

Only $1,998.30 - $2,510.00

Reviews (0)

SKU:: RQ-VESL-OLA-OLF

Request quote for availability

Description
Reviews
Additional Info

Description

The Overhead Load Lifters are designed for lifting and moving pallets, skids, and crates with an overhead lifting crane. Includes an adjustable bail for keeping the load level when moving. Includes (3) three height positions. Welded steel construction. Painted finish.

DELUXE WITH ADJUSTABLE FORKS 13" TO 38" O.D.

MODEL NUMBER	MINIMUM HEIGHT CLEARANCE	MAXIMUM HEIGHT CLEARANCE	USABLE FORK SIZE (W X L)	UNIFORM CAPACITY	WEIGHT (POUND)
OLA-2-36-DLX	42 5/8 ", 54", 65 3/4"	55", 66 13/16", 78 9/16"	4" x 36"	2,000 lb.	527
OLA-2-42-DLX	42 5/8", 54", 65 3/4"	55", 66 13/16 ", 78 9/16"	4" x 42"	2,000 lb.	538
OLA-4-36-DLX	42 5/8", 54", 65 3/4"	55", 66 13/16 ", 78 9/16"	4" x 36"	4,000 lb.	547
OLA-4-42-DLX	42 5/8", 54", 65 3/4"	55", 66 13/16", 78 9/16"	4" x 42"	4,000 lb.	558

ADJUSTABLE FORK WIDTH 17-5/8" TO 35-5/8"

MODEL NUMBER	MINIMUM HEIGHT CLEARANCE	MAXIMUM HEIGHT CLEARANCE	USABLE FORK SIZE (W X L)	UNIFORM CAPACITY	WEIGHT (POUND)
OLA-2-42	54", 64 9/16", 75 1/4"	59 3/8 ", 71", 83"	4" x 43 3/16"	2,000 lb.	537
OLA-4-42	54", 64 9/16 ", 75 1/4"	59 3/8", 71", 83"	4" x 43 3/16"	4,000 lb.	558

FIXED FORK WIDTH AT 27"

MODEL NUMBER	MINIMUM HEIGHT CLEARANCE	MAXIMUM HEIGHT CLEARANCE	USABLE FORK SIZE (W X L)	UNIFORM CAPACITY	WEIGHT (POUND)
OLF-2-42	50", 61 11/16", 73 3/16"	57 9/16", 69 5/16", 81"	4" x 37"	2,000 lb.	488
OLF-4-42	50", 61 11/16", 73 3/16"	57 9/16", 69 5/16", 81"	4" x 37"	4,000 lb.	491
