LMV-300 - Milling Machine - Heavy-Duty Performance, Compact Design

The LMV-300 is a compact industrial 3-axis CNC mill designed for precision machining in space-limited environments.

With a sturdy cast iron frame, high-speed spindle, and precision ball screws, it delivers reliable performance for demanding applications.

Its small footprint makes it ideal for workshops or production floors, while optional upgrades like a 4th-axis and automatic tool changer add versatility.

Perfect for small-batch production, prototyping, and precision parts, the LMV-300 offers industrial-grade performance in a space-efficient package.

Automate Your LMV-300 with the FANUC CRX-5iA or FANUC LR-Mate 400iD (RFQ for more details)

General Specifications (see downloads section for more information):

• Travel:  X 390 mm (14.5"),  Y 240 mm (9.4"), Z 194 mm (8")
• C7 Pre-loaded ball screws on all axis
• Linear guideways on all axis
• Granite and aluminum body
• 220 VAC, 20 A
• Fanuc Control - Model: 0i-MF
• Servo Motor: 350 W Brushless AC type for X, Y and Z axis, 6,000 RPM
• Direct drive on all axes
• Industrial Control with 10.4"" LCD screen
• MDI unit and standard operator panel
• FOV/SOV controls and panel mounted MPG
• LS-C30 Auto Tool Changer (Levil) - Standard Spindle 14,000 RPM, 2 HP, S20T taper, liquid-cooled
• Requires S20T style tool holders - Includes a 5 station Tool Rack
• 300 Steel Enclosure -Steel enclosure with polycarbonate windows, Aluminum Stand
• Safety Door Interlock Sensor
• Flood Coolant System - 10 Gallon Tank, 1/8 HP pump, 1,500 RPM, Adjustable flow valve, M-Code controlled
• Milling Starter Support Kit, 3" Vise, 3" Parallels set, Electronic Height Gauge, Edge finder, Clamping Kit, 6 mm T-Slots, 42 pcs
• 3000 Watt Voltage Converter Transformer Step Up/Down - 110V/220V

DOWNLOADS:

LMV-300 Brochure

All Levil Tech Brochure 2026

Levil Machines Comparison Chart
